Prime Time – Kiln Shelf and Mold Prep Tips You’ll Love


As seen in Fused Vessel Sinks with Lisa Vogt Video DVD

We are an ever-growing community. The wonderful thing about glass fusing is you can jump right in and start making beautiful projects with little or no experience. It’s this ease of fabrication that attracts so many new artists to the medium. Building the projects is the fun and easy part. Successfully firing and slumping the projects is where a little background knowledge comes in handy.

For the experienced glass crafter, with an established firing routine, this material may be a review and confirmation you’re on the right track or it might give insight into a new, possibly easier method you were overlooking.

If you’re a learn as you go beginner, or fresh out of an introductory class, this information will give you a deeper understanding of the importance of kiln shelf and slumping mold preparation.

As seen in Fused Vessel Sinks with Lisa Vogt Video DVD

Let’s get started.

What you need to now.

It’s necessary to apply and even coat of shelf primer (also known as kiln wash or separator) to the firing surface prior to fusing or slumping glass on that surface. Shelf primer acts as a separator. It prevents the super-heated glass from sticking to the kiln shelf during the fusing process, or the mold, during the slumping or draping process.

There are several different brands of shelf primer. Some come dry and are mixed with water. Others come premixed in a spray can. They all work equally as well, but some are better suited for specific techniques than others. For example, if a primer is intended to work up to 1550 degrees it wouldn’t be a good choice for glass combing which is done at 1600 degrees. You’ll find this kind of information on the product label. It’s always a good idea to refer to the manufactures suggested specs for guidance prior to use.


As seen in Fused Vessel Sinks with Lisa Vogt Video DVD
When I full fuse glass, I prime the kiln shelf, whether it’s a ceramic or fiber board shelf, every time I use it. That way I’m certain the glass won’t stick to the surface.

When fused glass sticks to a ceramic shelf the project breaks because the glass is more fragile than the ceramic shelf. When fused glass sticks to a fiber board shelf the project remains intact. But the glass pulls a chunk out the shelf and leaves an ugly hole behind, then you have to scrape the chunk of shelf off the backside of the glass. The residual shelf often leaves an unattractive haze on the back of the project, so it’s worth avoiding.

As seen in Fused Vessel Sinks with Lisa Vogt Video DVD
To prime a ceramic or fiber board kiln shelf I mix the dry primer with water according to the package directions. When preparing a pre-used shelf, I apply the primer in one direction with a wide natural bristle brush. A second coat is applied in a different direction. And then a third coat is added. I’m looking for a smooth, even colored coating.


If in doubt, add another coat of primer, it won’t hurt. If the primer begins to clump and isn’t going on smoothly any longer you’re on the verge of over doing it. Stop. Let the shelf dry and then hand rub the shelf to smooth out the surface.

Brand new shelves are more porous and require more coats of primer the first time they’re prepped. It may take as many as 5 or 6 coats to get the same even coating and smooth surface.

On pre-used ceramic shelves, I prime right over the spent primer. However, if the primer is chipped or flaking I sand or scrape the old coating completely off. Once the old primer is removed, I re-prime the shelf as previously described.

For fiber board shelves, I prime right over the spent primer even if it has chips, flakes or cracks in the old primer. The fresh coat of primer re-seals the shelf and smooths out the blemishes.

Priming molds.


Glass fuses at 1465 degrees. Glass slumps at 1265 degrees. I use the same primer on my kiln shelves as I do on my slumping molds. The primer is designed to go to temperatures higher than 1600 degrees.

When we slump glass at 1265 degrees we’re well below the primer’s top temperature. I use my ceramic and stainless steel slumping molds multiple times before re-priming them. I re-prime them when the old primer shows signs of wear. Signs of wear would include thin patches, exposed mold surfaces, cracks, chipping or flaking. When these flaws are visible, I sand the mold down to the bare material and then apply three coats of primer until I get a smooth even coating.

Good housekeeping.

The primer I use is pink before firing and white after firing. I have multiple shelves for each of my kilns. If a primed kiln shelf sits around for a while the pink color can fade. It makes it difficult to tell if the primer is new or not. To keep track of my prepared shelves, I store my primed shelves leaning against the wall, behind the kilns they fit in. After a shelf is used I lean it against a different wall in my studio. When the stack is thick, I prime all the used shelves at one time. The newly primed shelves are then stored behind the kilns. It’s a simple system, but it works.

My slumping molds are stored on shelves. Because they’re used multiple times before re-priming, their primer color is white, not pink. Coming out of the kiln, if I determine a mold needs to be re-primed, it doesn’t go back on the shelf until it is re-primed. Then when I reach for a mold off the shelf I know it’s ready to use.

The more you know about glass fusing and the procedures that lead to successful kiln operation, the more likely you are to delve deeper into the craft. With the working knowledge taken care of you can focus on the fun stuff, creating.

Get going!

Happy fusing!
Lisa

See priming a shelf and mold on YouTube
